IPQ9574 vs IPQ5424: A Comprehensive Technical Comparison of Wi-Fi 7 SoCsAs Wi-Fi 7 (802.11be) enters commercial deployment, system integrators are demanding higher performance, scalability, and ecosystem compatibility from network SoCs. Qualcomm, a leading innovator in this space, has launched multiple Wi-Fi 7 platforms to address diverse needs. Among them, the IPQ9574 and IPQ5424 stand out—targeting enterprise-grade and cost-optimized consumer/prosumer segments respectively.
This article provides a detailed, side-by-side comparison of these two SoCs, examining architecture, RF capabilities, software support, and application suitability to help developers make informed choices.\
1. Positioning & ArchitectureFeatureIPQ9574IPQ5424
Market SegmentEnterprise AP / Industrial Mesh / High-end CPEMid-to-high Mesh Routers / Home Gateway / SMB CPE
CPU ArchitectureQuad-core ARM Cortex-A73 @ 2.2GHzQuad-core ARM Cortex-A53 @ 1.5GHz
Network SubsystemQualcomm NSS (Network Acceleration)Fast Path only
Process Node14nm14nm
Memory SupportDDR4 / DDR5 (Up to 6.4Gbps+)DDR3L / DDR4 (Up to 2.4Gbps)
PCIe InterfacePCIe Gen4 x2/x1PCIe Gen3 x1 (Dual-lane)
USB SupportUSB 3.0USB 2.0 / USB 3.0 (varies)Insight: IPQ9574 provides higher throughput and concurrency thanks to its Cortex-A73 cores and dedicated NSS engine. In contrast, IPQ5424 is a cost-effective alternative designed for efficient, lower-power implementations. 2. Wi-Fi 7 Radio Capabilities (with 6GHz Support)FeatureIPQ9574IPQ5424
Frequency Bands2.4GHz / 5GHz / 6GHz (Tri-band)2.4GHz / 5GHz / 6GHz (Tri-band)
Max BandwidthSupports 320MHz (6GHz)Supports 320MHz (6GHz)
Spatial Streams4x4x4 MU-MIMO2x2 + 2x2 Concurrent
OFDMA / MU-MIMOFull supportBasic support
MLO (Multi-Link Operation)SupportedSupported
BeamformingAdvancedBasic
OpenWRT/OpenWiFi 6GHz SupportNot supported currentlyNot supported currentlyNote: Although both chips technically support the 6GHz band and Wi-Fi 7 features, current open-source platforms like OpenWRT and OpenWiFi do not fully support 6GHz due to driver and regulatory limitations. Custom firmware or vendor SDKs are recommended for full feature enablement. 3. Interfaces & ExpandabilityFeatureIPQ9574IPQ5424
EthernetUp to 1x 10G SFP+, multiple 2.5G / 1G ports2x 2.5G or 4x 1G options
PCIe ExpansionIdeal for QCN9274/QCN6274 Wi-Fi 7 NICsCompatible with dual-band Wi-Fi modules
USB PeripheralsUSB 3.0 for high-speed use casesUSB 2.0/3.0 for basic expansion/storage4. Software Ecosystem & Platform SupportFeatureIPQ9574IPQ5424
SDK AvailabilityQualcomm QSDK / YoctoQualcomm QSDK / Yocto
OpenWRT SupportSupported (6GHz excluded)Supported (6GHz excluded)
OpenWiFi SupportEarly-stage integration; not fully stableBasic support; limited 6GHz features
Security FeaturesSecure Boot / TPM / TrustZoneSecure Boot / TrustZone
Cloud IntegrationPlume, Ruckus, OpenWiFi controllerHome/ISP cloud systems5. Application Scenarios✅ Recommended for IPQ9574:
6. Selection SummaryFeatureIPQ9574IPQ5424
Performance Level★★★★★★★★☆☆
Ecosystem Maturity★★★★☆ (vendor stack needed)★★★☆☆
6GHz Usability (now)★★☆☆☆ (requires custom drivers)★★☆☆☆ (limited by OSS)
Tri-band NIC CompatibilityExcellentModerate
Product DifferentiationHigh (flagship class)Mid (value-driven)ConclusionThe IPQ9574 and IPQ5424 represent Qualcomm’s strategic push into the Wi-Fi 7 SoC market. IPQ9574 excels in high-throughput, tri-band, and enterprise use cases, while IPQ5424 enables more cost-efficient mass-market products.
Both chips offer full 6GHz hardware support, but developers should note that open-source platforms like OpenWRT and OpenWiFi currently lack stable 6GHz support. For full functionality, leveraging Qualcomm's QSDK or integrating with vendor firmware stacks is recommended.
